Electro-Static Discharge (ESD) arises from friction and material separation, a common physical phenomenon. Humans can perceive static electricity starting at 3500V, yet for semiconductor precision electronic components, static electricity as low as 35V can cause irreversible permanent damage. Such ESD damage is highly concealed: it produces no sound and leaves no visible marks throughout production, even though internal component failure has already occurred. This triggers a chain of consequences: frequent equipment and system malfunctions, degraded product quality, higher scrap rates, increased maintenance costs, along with risks of customer complaints and claims.
Conclusion: ESD protection is not an optional upgrade for production lines handling sensitive components, but a fundamental manufacturing requirement.
Many production lines prioritize ESD control on workbenches, floors and work garments, yet frequently overlook cable chains — critical components undergoing continuous reciprocating motion within automated production lines. Per IEC specifications, cable chains fall under the category of “other surfaces (non-working surfaces)”, with a maximum allowable surface resistance of 10¹¹Ω.
| Material Category | Surface Resistance Range | Static Characteristics |
|---|---|---|
| Conductor | ＜10⁵Ω | Rapid charge dissipation with risk of sparking |
| Dissipative Semiconductor | 10⁵~10¹¹Ω | Enables controlled, gradual static discharge within the safe range |
| Insulator | ＞10¹¹Ω | Prone to charge accumulation, high risk of electrostatic breakdown |
DURAMOV® ESD Cable Chains adopt engineering plastic base material homogeneously blended with conductive modifiers. The entire link structure delivers stable anti-static performance, with surface resistance consistently below 10⁹Ω, falling within the safe static dissipation range. The products comply with IEC 61340-5-1 ESD protection standard. They steadily dissipate static charges generated by friction during reciprocating movement of cables, preventing damage to chips and precision electronic components caused by weak static electricity as low as 35V. Suitable for high-cleanliness, ESD-controlled automated working environments including semiconductors, display panels, lithium batteries and precision inspection.
Four Main Series of DURAMOV® ESD Cable Chains: C01E / C21E / C31E / C02E
| Series | Product Positioning | Core Structural Features | Size Range | Core Advantages |
|---|---|---|---|---|
| C01E | Mini Non-Openable ESD Cable Chain | Integrally molded structure; non-laterally openable links; short pitch design for lower running noise | Inner height: 7/10/15 mm; Inner width: 7~50 mm, multiple bend radii available | Compact and lightweight with cost-effective performance. Designed for space-restricted installation scenarios. Small bend radius, smooth and low-noise operation, ideal for miniature precision motion modules |
| C21E | Mini Openable ESD Cable Chain | Split lateral opening structure for easy assembly and disassembly; stable operation under high-speed conditions | Inner height: 10/20 mm; Inner width: 10~50 mm | Lightweight construction for high-speed reciprocating motion. Single-side opening simplifies cable routing and later maintenance, suitable for compact precision automation equipment |
| C31E | Mini Openable ESD Cable Chain | Flip-style crossbar on one side, drastically cutting assembly time | Inner height: 10~20 mm; Inner width: 10~50 mm | Side flip design allows cable installation and inspection without full disassembly of the chain. Dividers can be fitted for independent routing of separate cables and hoses |
| C02E | General-Purpose ESD Cable Chain | High-strength modular multi-opening structure, optional dividers and strain relief accessories | Inner height:18~45 mm; Inner width:38~250 mm, large-size options available | The most versatile ESD cable chain. High structural strength and quiet operation, effectively extending cable service life. Rich accessory options, applicable to medium & large automated conveying, wafer processing equipment and inspection machines |
ESD Performance: Surface resistance consistently below 10⁹Ω. Bulk modification of substrate material, different from surface coating solutions. Anti-static properties remain intact after long-term reciprocating wear.
Temperature Resistance: Continuous operating temperature -40℃ ~ +120℃, compatible with high and low temperature conditions in semiconductor workshops.
Running Performance: Low friction and low noise. Capable of high acceleration and long unsupported travel, protects high-flex cables and hoses during reciprocating motion.
Cleanroom Compatibility: Low particle generation, suitable for cleanroom environments and meets cleanliness requirements of semiconductor production lines.
Semiconductor wafer processing equipment, SMT production lines, display panel manufacturing lines, lithium battery electrode equipment, precision inspection instruments, robotic mobile cable modules, cleanroom automated conveying lines.
| C01E | C21E | C31E | C02E |
| Mini Non-Openable ESD Cable Chain | Mini Openable ESD Cable Chain | Mini Openable ESD Cable Chain | General-Purpose ESD Cable Chain |
 |  |  |  |
Miniature motion units in confined spaces → C01E
Confined spaces requiring frequent cable replacement and maintenance → C21E / C31E
Medium-to-long travel, heavy load, multi-cable/hose bundles requiring separation → C02E
All E-series ESD cable chains feature bulk modified anti-static technology. Unlike coated anti-static cable chains, they will not lose anti-static capability under continuous friction and wear.
Conventional insulating cable chains have surface resistance above 10¹¹Ω. Static charges continuously accumulate during reciprocating motion, which easily leads to latent ESD breakdown of electronic components. DURAMOV®-E Series ESD cable chains achieve controlled static dissipation, eliminate electrostatic hazards originating from moving cables, protect precision electronic components and stabilize production yield.
