CSB-EPB® Plastic plain bearings

Product properties

CSB-EPB® Plastic plain bearings use high-performance plastics as the raw material, and filled high-strength fibers and special solid lubricants by the polymer compound technology to improve the anti-wear resistance of composite materials.
In the automotive industry with high durability requirements, high-speed applications, underwater applications, high temperature and anti-corrosion applications, or the food industry with FDA requirement, CSB can always provide different solutions for customers.


EPB Plastic plain bearings
EPB Plastic plain bearings

The most versatile CSB® plastic palin bearings. It can meet most applications at operating temperatures below 250°C. Excellent wear resistance and reasonable price are usually the materials of choice for design engineers.

more
PCB Plastic clip bearings
PCB Plastic clip bearings

The self-lubricated bearing is developed specially for the metal plate fitting. It is made with the CSB-EPB3M material which is good at shock absorbtion and wear resistance...

more
PYB Small thickness  plastic bearings
PYB Small thickness plastic bearings

Thin-wall plastic bearing for quick installation. It is made with CSB-EPB3M material wich is flexible for dimension viriation. Alternative material CSB-EPB7 is also available for special wear resistance requirement.

more
CPB Clearance-free and preloaded bearings
CPB Clearance-free and preloaded bearings

● Clearance-free and preload design
● Adjustable fitting gap
● Maintenance-free
● Shock absorbing and no noise

more
FLB Plastic flange bearings
FLB Plastic flange bearings

Suitable for the application where the CSB® plastic clip bearing is hard to be located. The requirement of the fitting hole is not critical and the set screw could be secured without any risk of moving.

more
PEW Plastic flat springs
PEW Plastic flat springs

CSB® plastic wear resistance washer. Suitable for a fitting to the uncontrollable axial space in order to reduce the vabriation and noise during the operation.

more
PPR Plastic piston rings
PPR Plastic piston rings

Wear resistance piston ring specially developed for the pneaumatic pump industrial application. It is easier to be installed comparing with the PTFE piston ring. Standard materials available are EPB13, EPB19 and so on.

more
LCB Linear clip bearings
LCB Linear clip bearings

● Made of high anti-wear material EPB13;
● Maintenance-free, self lubricating;
● Chemical resistant;
● Dust resistant and quit running;

more
KER Knife edge rollers
KER Knife edge rollers

Self-lubricating, maintenance-free Low driving force Resistant to dust...

more

CSB-EPB® Plastic bearings and metal bearings

Because the grease immersed in the solid plastic material, the lubricating will be valid continuously no matter how long the bearings are working. Therefore, the traditional sintered oilless bearings provide the lubricating function by utilizing the impregnated oil in the tiny porosities of the material. When the impregnated oil would have been run out of dried, the bearing wear will be increased sharply and the bearing life will be terminated at the same time.

CSB-EPB® Bearing friction coefficient

The self-lubricating feature of the CSB-EPB® plastic bearing is achieved by adding solid lubricants and functional fibers into the body material and the friction coefficient is decreased by the solid lubricate grease immersion. The friction coefficient is affected by the load, operating speed and shaft roughness. The friction coefficient is generally decreased along the load increasing and increased along the operating speed (see Graph3). Please refer to Graph 3 for the relation between the friction coefficient and shaft roughness.

CSB-EPB® Plastic bearing wear

Slightly wear off will occur as soon as the self-lubricating bearing is applied with a certain load. It is the same to the CSB-EPB® plastic bearings, when the slightly wear occurs, the immersed oil (grease) will infiltrate out from the bearing filling the wear off area of the bearing as well as the mating material to form the lubricating film (Graph 4) and therefore interrupt the wear process. In this way, the aforementioned working method of the plastic bearings improves the wear resistance feature of the bearings and maintains the further operation stable.

CSB-EPB® Plastic Bearings Finder[V2.0] is based on the analysis and calculation of a large number of test data in CSB laboratory. You can calculations material data by entering parameters such as bearing load, speed, and temperature, and finally output material adaptation data.
Because the system calculate and analyze based on lab data, it can't exactly meet the ractual use requirements absolutly. The system data verification has certain limitations; CSB recommends that the bearing must be tested again to verify whether it meets the actual use requirements.
CSB-EPB® Plastic Bearings Finder output data information is only for design reference, and can not be used as the final standard for determining the bearing material conformity, If you have any questions, please contact CSB sales engineers.

CSB-EPB® Plastic Plain Bearings

Type PDF
Size 3.42MB
Time 03-2020
No. CSB/CAT.052
download

500

CSB-PCB® Plastic Clip Bearings

Type PDF
Size 249KB
Time 03-2020
No. CSB/CAT.052
download

422

CSB-CPB® Clearance-free and preloaded bearings

Type PDF
Size 163KB
Time 03-2020
No. CSB/CAT.052
download

398

CSB-LCB® Linear clip bearings

Type PDF
Size 141KB
Time 03-2020
No. CSB/CAT.052
download

388

CSB-PYB® Small thickness plastic bearings

Type PDF
Size 173KB
Time 03-2020
No. CSB/CAT.052
download

390

CSB-FLB® Plastic flange bearings

Type PDF
Size 176KB
Time 03-2020
No. CSB/CAT.052
download

380

CSB-PEW® Plastic flat springs

Type PDF
Size 186KB
Time 03-2020
No. CSB/CAT.052
download

369

CSB-PPR® Plastic piston rings

Type PDF
Size 160KB
Time 03-2020
No. CSB/CAT.052
download

374

CSB-KER Knife edge rollers

Type PDF
Size 118KB
Time 03-2020
No. CSB/CAT.052
download

292

MediumBearings resistance
AlcoholFind on the detail page
HydrocarbonsFind on the detail page
Greases. oilsFind on the detail page
FuelsFind on the detail page
Diluted acidsFind on the detail page
Strong acidsFind on the detail page
Diluted alkalisFind on the detail page
Strong alkalisFind on the detail page
CSB® Bearing Material Chemical Resistance

Please select bearing material and medium...

CSB® bearing material chemical resistance data is a comparison test result of the CSB chemistry laboratory using laboratory specimens or similar chemicals at room temperature 23 ℃, without considering the impact of other temperatures and chemical medium mixtures on the chemical resistance of CSB® bearing materials ; Therefore, this data can only act as a reference. CSB® recommends that the chemical resistance of actual parts should be tested under application conditions and verify the suitability of the bearings.
