WRC01 Round guide rail carriages,MN2

Product properties

● MN2 liners for aluminum shafts

● Maintenance-free, dry-running

● Fast assembly and light weight

● For WR dual guide rails

● Resistant dust and silent

● Silent operation

● Variable length can be fitted



WRC01 Round guide rail carriages,MN2
Dimensions

WRC01 Assembled guide carriages load capacity

Part No.

Static load
Weight
Coy- [N]
Coz [N]
Mox [Nm]Moy [Nm]Moz [Nm]
[kg]
WRC01-10-40-100-MN2
48002400961701700.29
WRC01-10-40-150-MN2
48002400962902900.34
WRC01-10-40-200-MN2
48002400964104100.4
WRC01-10-80-100-MN2
480024001781701700.34
WRC01-10-80-150-MN2
480024001782902900.42
WRC01-10-80-200-MN2
480024001784104100.5
WRC01-16-60-100-MN2
840042002402702700.71
WRC01-16-60-150-MN2
840042002404804800.84
WRC01-16-60-200-MN2
840042002406906900.97
WRC01-20-80-150-MN2
1280064005256706701.2
WRC01-20-80-200-MN2
1280064005259909901.3
WRC01-20-80-250-MN2
128006400525125012501.5

Eccentric forces

● Maximum 2:1 ratio

● 1x = bearing separation on same shaft

● 2x = distance from shaft to load or force

CSB-LIN®直线轴承安装法则

● CAUTION: uneven motion or even system blockage will occur if the 2:1 ratio is exceeded !

This principle is NOT load dependent! It is NOT due to edge loading. It is also NOT dependent on the driving force used! The greater the distance between the drive and guide bearings, the higher the degree of wear and required drive force.

There may be other factors that add to the braking effect, but the coefficient of friction is the main cause.

● NOTE: The Rule(2:1) is based on the static friction value of 0.25 theoretically, However, Additional lubrication can help to drop friction and extend the 2:1 ratio.

● If you have any questions on design and/or assembly, please contact our application engineers.


WR02 Double round linear guide rails
WR02 Double round linear guide rails

● Dual guide rails made of aluminum

● Hard anodized surface

● Weight saving and no noise

● Standard fitting width

more
WRU01 Round rail sliding blocks, MN2
WRU01 Round rail sliding blocks, MN2

● MN2 liners for aluminum shafts

● Maintenance-free, dry-running

● Fast assembly and light weight

more

CSB-LIN® Plastic Linear Bearings Finder[V2.0] including LIN plastic linear bearings and LINP precision linear bearings. The system is based on the analysis and calculation of a large number of test data in CSB® laboratory. You can calculations bearing data by entering parameters such as bearing load, speed, temperature and position information, The system will output bearing adaptation data and min. driving force.
Because the system calculate and analyze based on lab data, it can't exactly meet the ractual use requirements absolutly. The system data verification has certain limitations; CSB® recommends that the bearing must be tested again to verify whether it meets the actual use requirements.
CSB-LIN® Plastic Linear Bearings Finder output data information is only for design reference, and can not be used as the final standard for determining the bearing material conformity, If you have any questions, please contact CSB® sales engineers.
